Service Product introduction:
The mechanical structure of this machine tool is mainly composed of frame, workbench, slide block, main cylinder and back stopper. Perfect design and manufacturing process can effectively ensure the manufacturing and use accuracy of machine tools.
Up-moving bending design, smooth work, easy to operate, safe;
The main parts of the machine, such as the frame, slide block and table, are finished by using a large planer to ensure the geometric accuracy requirements of the main machine.
The guide rail of the machine tool adopts advanced self-lubricating materials, which does not require frequent lubrication maintenance;
Hydraulic upper transmission.
Standard simple control system, convenient and fast.
High-end CNC system and supporting parts can be configured according to customer selection.
Specifications:
|
Model number |
Nominal force |
Collapsible plate width |
Throat depth |
Slide travel |
Main motor power |
|
WC67Y/K-40/2500 |
400 |
2500 |
200 |
70 |
7.5 |
|
WC67Y/K-80/2500 |
800 |
2500 |
250 |
100 |
7.5 |
|
WC67Y/K-100/2500 |
1000 |
2500 |
250 |
100 |
7.5 |
|
WC67Y/K-100/3200 |
1000 |
3200 |
320 |
100 |
11 |
|
WC67Y/K-100/4000 |
1000 |
4000 |
320 |
100 |
|
|
WC67Y/K-125/2500 |
1250 |
2500 |
320 |
100 |
11 |
|
WC67Y/K-125/3200 |
1250 |
3200 |
320 |
100 |
11 |
|
WC67Y/K-125/4000 |
1250 |
4000 |
320 |
100 |
15 |
|
WC67Y/K-160/3200 |
1600 |
3200 |
320 |
150 |
15 |
|
WC67Y/K-160/4000 |
1600 |
4000 |
320 |
150 |
18.5 |
|
WC67Y/K-200/3200 |
2000 |
3200 |
320 |
150 |
18.5 |
|
WC67Y/K-200/4000 |
2000 |
4000 |
320 |
150 |
18.5 |
|
WC67Y/K-250/3200 |
2500 |
3200 |
320 |
150 |
22 |
|
WC67Y/K-250/4000 |
2500 |
4000 |
320 |
150 |
30 |
|
WC67Y/K-300/4000 |
3000 |
4000 |
350 |
180 |
37 |
Note: Specifications and details are subject to change without prior notice.
